ECN035-04P3-02P2-13S is CENO new designed through hole slip ring which suits for low temperature environment, such as Aviation, Diving equipment, Test instrument or the harsh environment application. This type slip ring can transmit electric power, 100M Ethernet signal stably from stator side to rotor side. And get another technical breakthrough / achievement in environment adaptability on the conductive slip ring. For more information please contact us, please contact us.
Specification
| ECN035-04P3-02P2-13S | Specification |
|---|---|
Current & Circuits | 4circuits*15A; 2circuits*10A; 8circuits*RS422 Signal; 1group*100M Ethernet |
Rating Voltage | 0~24VAC/VDC |
Dielectric strength | ≥500VAC@50Hz |
Isolation resistance | ≥500MΩ@500VDC |
Contact resistance | 30mΩ (50rpm) |
Contact material | Precious Metal |
Housing material | Aluminum Alloy |
Working temperature | -40°C~+65°C |
Working humidity | 60%RH |
IP protection grade | IP51 |
Operating speed | 0~300rpm |
Inner bore | Ø35mm |
Lead wire length | Rotor:300mm; Stator:300mm |
Lead wire size | AWG14# 17# Tin coated Teflon® UL; 4 core twist shielded wire; CAT5e |
Outline drawing
