ACN25-02P-01S is CENO's new product named capsule slip ring which is designed for Robot application or the limited space. The feature of this series product are small compact structure, military grade surface treatment technology, it can provide high speed, long service life, high protection and rotate 360° to transmit data, or electrical signals stably. For more information about how CENO's slip ring to suit for your specific environment, please contact us.
Specification
| ACN25-02P-01S | Specification |
|---|---|
Current & Circuits | 2circuits*20A; 1 circuit*CANBUS signal |
Rating Voltage | 48VAC/1A |
Dielectric strength | ≥500VAC@50Hz |
Isolation resistance | ≥100MΩ@100VDC |
Contact resistance | 10mΩ (50rpm) |
Contact material | Precious Metal |
Housing material | Aluminum Alloy |
Working temperature | -20°C~+80°C |
Working humidity | 95%RH |
IP protection grade | IP51 |
Operating speed | 0~300rpm |
External diameter | Ø25mm |
Outline drawing
