Field-bus is an open, fully digital, two-way, multi-station communication system, which has been developed rapidly in recently years.And it iswidely applied in Field intelligent equipment interconnected communication network, such as automation, process automation, electric automation,building automation,etc. It serves as the basis for the communication digital network of the factory with effective communication between equipment and equipment, and between equipment and higher control system.Aiming at the different application requirements of Fieldbus ，such as CAN, Profibus and field Ethernet, CENO has been developped different kind of slip ring to meet related requirement.
Feature
Transmit various signals such as RS, NET and other serial port and bus signals;
Simultaneously transmit servo motor current and encoder control signals
Stably transmit, with no package loss, no cross talk,low loss.
Integrate multi-signal and current.
Comply with EMC compatibility, without interference between current and signal
Application
Motion simulation Equipment
Automatic Equipment
| Model | ID (mm) | OD (mm) | CKT No. | Current/Signal | Voltage | Working speed RPM | Spec |
|---|---|---|---|---|---|---|---|
| ECN000-26P2-02P-08S-01E | 0 | 47 | 37 | 26* 10A, 2*4A, 2*485 signal; 2*can signal, 1* Megabyte Ethernet signal | 48VAC/VDC | 0~200 |  |
| ECN000-05P2-05S | 0 | 54 | 6 | 5 circuits * 10A, 1circuit * Profinet | 0~480VAC/VDC | 0~250 |  |
ECN000-09P-EM-23S | 0 | 56 | 32 | 4*10A,3*5A,3*2A(1*2A*PE),23*signal, 1*1A,2*1A,1*100M Ethernet | 0-24VAC/VDC | 0~300 | |
| ECN000-0250-04S | 0 | 65 | 3 | 2 * 50A; 1 * CANBUS | 0~240VDC | 0~300 | |
| ECN000-04P2-04P1-08S-01EG | 0 | 90 | 17 | 4*10A,4*5A,4 group*RS422 signal,1 group*1000M Ethernet | 24VDC | 0~250 | |
| ECN000-07P-68S | 0 | 110 | 75 | 3*35A; 2*20A; 20*10A; 40*in/out put signal; 2*Link Bus wires; 10*5A(in reserve) | 0~380VAC/VDC | 0~ 30 | |
| ECN000-04P2-04S-IP66 | 0 | 130 | 8 | 4 circuits * 10A; 1 * Profi net signal | 0~220 VAC / VDC | 0~300 |  |
| ECN000-05P4-04P3-11S | 0 | 140 | 13 | 4*25A (630VAC); 1*25A (PE); 4*16A (250VAC); 1*Profibus Signal; 8*3A (30VAC) | 0-630VAC/VDC | 0~10 |  |
| ECN025-28P1-08S-03EM | 25 | 74 | 39 | 22*5A,2*PE,4*5A,2*RS485,3*100MEthernet | 220VAC/48VDC/24VDC | 0~300 |  |
| ECN025-18P2-26S | 25 | 86 | 44 | 20*10A,3* communication signal,32*1000M Ethernet,3*signal | 380VAC/24VDC | 0-300 |  |
| ECN025-20P2-38S | 25 | 86 | 58 | 18* 10A,4*servo motor encoder signal 8*sensor signal，2*reserve | 380VAC | 0~300 |  |
ECN025-25P2-04EG | 25 | 99 | 29 | 25*10A,4*Cat5e | 380VAC/24VDC | 0~300 |  |
ECN038-05P-08S-01EM | 38 | 99 | 14 | 3*15A,2*10A,4*422/232,1*PE 1 group*100M Ethernet | 0~380VAC/VDC | 0~300 |  |
| ECN038-06P-02S-01EM | 38 | 119 | 8 | 2*20A; 2*30A; 2*5A; 1Group*RS232 Signal; 1group*Profinet | 0~480VAC/VDC | 0~300 | |
| ECN095-03P4-04S | 95 | 185 | 7 | 3*20A, 4*Profi-bus Signal | 0~115VAC/VDC | 0~350 | |
| ECN240-16P-33S-IP65 | 240 | 365 | 49 | 5*40A, 10*20A, 1*PE, 10*2A, 5*Can-Bus, 8*Signal | 380VAC/ 220VAC /24VDC | 0~10 |  |
| QCN0201-07P-02EG | 0 | 100 | 9 | 5*25A; 2*20A; 2 group 1000M Ethernet signal | 380VAC/DC | 0~100 |  |
| SCN500-03P4-04S | 500 | 558 | 6 | 3*25A; 1*CAN Signal; 2*IO Signal | 240VAC/VDC | 0~100 |  |
