CENO'S HDMI slip ring adopts domestic leading military technology, it has the advantages on transmission stability, attenuation loss of signal and ultra-low transmission fluctuation.This kind of high definition slip ring includes SDI high resolution and HDMI, which transmits electrical signals ,video signals and high-speed digital signals to meet EMC requirements.CENO also can provide different solutions according to customer's requirements.
Feature
It can support video standard of 2K@90Hz,no flicker screen and losing frame
Gold to gold contact point to guarantee extending working lifespan
Low contact resistance, compact size, low torque, reliable operation
Application
HDMI Security system
Infrared photography
High definition PTZ
Photooelectric pod
Radar antenna
| Model | ID (mm) | OD (mm) | CKT No. | Current/Signal | Voltage | Working speed | Spec |
|---|---|---|---|---|---|---|---|
| BCN-02P1-08S-01HD | 0 | 12.4 | 2*5A; 8*Signal; 1*HDMI | 0~24 VAC/VDC | 100rpm or higher |  | |
| ACN20-04P-20S-03HD | 0 | 20 | 27 | 4*1A; 7*2A; 2*8A;2*6A;4*1A; 4*1A; SDI*2; PAL*1 | 0~24 VAC/VDC | 0~30rpm |  |
| ACN-04P1-08S-02HD | 0 | 21 | 14 | 2*4A, 2*3A, 2*Control Signal, 2*sine Signal; 8*R422 Signal, 1*GND, 2*(HD-SDI) | 0~24 VAC/VDC | 0~60rpm | |
| ACN22-03P1-04S-01HD | 0 | 22 | 8 | 3*5A; 1*3G-SDI; 4*232 | 0~100 VAC/VDC | 0~300rpm | |
| ACN022-30P-01EM | 0 | 22 | 31 | 1*HDMI; 1*PLA Analog Video Signal; 1*RS422; 1*100M Ethernet; 2*Sine Signal; 13*2A; 2*1A. | 0~48VAC/VDC | 0~300rpm | |
| ACN25J-09P1-19P-02HD | 0 | 25 | 30 | 2* HD-SDI; 19* 2A; 9* 5A | 2-110VAC/VDC | 0~50rpm | |
| ACN25J-04P1-30P-01HD-01EM | 0 | 25 | 36 | 30*2A,4*5A,1*HD-SDI,1*100M Ethernet. | 0-110 VAC/DC | 0-200 rpm |  |
| ACN25J-04P1-30P-01HD-01EG | 0 | 25 | 36 | 30*2A; 4*5A; 1*SDI; 1*Gigabit Ethernet | 0-110 VAC/DC | 0-200 rpm |  |
| ACN-30S-01EG-01UB-01HD-01R | 0 | 45 | 33 | 30* 2A, 1*Gigabit signal 1*USB,1*HD-SDI | 100VAC/VDC | 0~50rpm | |
| ECN000-02P1-02P2-02P-30S-HD | 0 | 62 | 36 | 2*10A,2*5A,2*2A,29*1A,1*video， 1*（HD-SDI） | 380VAC | 0~30rpm | |
| ECN000-03P-04P2-23S-01HD | 0 | 49 | 31 | 3*20A ,4*10A ,23*signal ,1*coaxial signal | 440VAC/250VDC | 0-100 rpm | |
| ECN000-04P1-02U2-01HD | 0 | 76 | 7 | 4*5A, 2*USB2.0 ,1*HDMI signal | 380VAC | 0~30rpm | |
| ECN000-07P-25S-01EG-01HD | 0 | 86 | 33 | 4*5A,3*10A,2*2A,4*RS422,1*1000M Ethernet,1*HDSDI,9*signal | 220VAC/24VDC | 0-150 rpm | |
| ECN000-01S-600 | 0 | 90 | 3 | 1* HD Signal; 1*Fiber(guest supply ); 1*shielded wire | 240VAC | 0~600rpm | |
| ECN004-04P-01S | 4 | 35 | 5 | 1*coaxial signal,4* ordinary signal | 380VAC | 0~400rpm | |
| ECN012-05P2-02S-HD02 | 12 | 56 | 9 | 2*video signal, 2*DP signal, 5*10A | 220VAC/12VAC | 0~300rpm | |
| ECN038-32S-03HD | 38 | 99 | 35 | 32*1A, 3*Bandwidth | 0~150 VAC/VDC | 0-250 rpm | |
