ACN30-14P1-04S-01EG-B Ethernet Signal Slip Ring

ACN30-14P1-04S-01EG-B is CENO capsule slip ring combine electric power, RS422 and Ethernet signal for industry and automatic machine. CENO Ethernet signal slip ring solutions have been developed to provide reliable products to allow transfer Ethernet protocol through a rotating interface. This designs meet the challenge of matching impedance, controlling crosstalk and managing loss. A wide range of product solutions are offered with combined power in multiple mechanical configurations to meet your application

Product Details

Specification

ACN30-14P1-04S-01EG-B	Specification
Current & Circuits	14 * 5A; 1 * RS422; 1 * 1000M Ethernet
Rating Voltage	0 ~ 28 VAC/VDC
Dielectric strength	≥500VAC@50Hz; ≥100VAC@50Hz
Isolation resistance	≥100MΩ@500VDC; ≥10MΩ@100VDC
Contact resistance wave	≤ 35mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Outer diameter	Ø30mm
Contact material	Precious Metal / Gold to gold
Housing material	Aluminium Alloy
Rotation way	Flange installation
Lead wire length	As customized
