FCN0203-44R

The Fiber optic rotary joint (FORJ) is the optical equivalent of the electrical slip ring. It allows uninterrupted transmission of an optical signal while rotating along the fiber axis. The FORJ is widely used in missile guidance systems, robotic systems, remotely operated vehicles (ROVs),oil drilling systems, sensing systems, medical devices (OCTs), broadcasting and many other field applications where a twist-free fiber cable is essential.

Product Details


FCN0203-44R

Specification

Fiber  type

SM/MM

Fiber channel

2-3

Connector type

FC/PC/LC/ST

Wave length range

1270-1610nm for SM;850 and 1310nm for MM

Insertion loss

< 5.5dB

Rotation speed,max

300rpm

Operation temperature

-20℃+65

Estimated life cycle

100-200 million revolutions

IP grade

IP65

Housing materia

Stainless steel

Package style

Receptacles(FC or ST; up to 3 channels)




Outline drawing
