ECN000-40P1-20S Multi-channels Signal Slip Ring

ECN000-40P1-20S is CENO multi-channels slip ring with 60 circuits for signal for commercial application. In CENO, multi channel slip ring is refer to the slip rings with more than 50 circuits, and can be integrated with kinds of data, electric or signals, such as HDMI data, weak or power electric, analog signal, FORJs / Fiber Optic Rotary Joint or RF Radio Frequency as customer detail requirement. This slip ring features high grade contact material and soft aviation wire to ensure low loss and smooth transferring. For more information about CENO slip ring, please contact us.

Product Details

Specification

ECN000-40P1-20S	Specificaton
Current & Circuits	20 circuits * Signal; 20 circuits * 2A (Power); 20 circuits * 2A ( Power compensation )
Rating Voltage	0-24VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥300MΩ@500VDC
Contact resistance	30mΩ (50rpm)
Contact material	Precious Metal
Housing material	Aluminum Alloy
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Lead wire size	Cable 8641; Cable 9948 ( guest supply )
Lead wire length	Rotor : 1000mm Stator : 3000mm
Rotation Way	Flange installation
