ECN025-15S

Through hole slip ring can be used in any electromechanical system that requires unrestrained.Slip ring is also called a rotary electrical joint,collector,commutator or swivel,slip ring can improve system performance by simplifying operation and eliminating damage prone wires.The inner hole size can be customized from 0-980mm.ECN025-15S provides an economical,readily available solution when a compact through bore configuration is required.This unit provides 25.4 mm through bore for routing hydraulic or pneumatic lines and a compact 86mm outside diameter for minimal space applications.It’s can integrated Ethernet,USB2.0, HDMI,fieldbus signal.

Product Details

Specification

ECN025-15S

Specification

Rings

15*1A

Voltage

0~35VAC/VDC

Electrical noise

≤30mΩ(50rpm)

Dielectric strength

≥500V@50Hz

Isolation resistance

≥250MΩ@250VDC

Operating speed

0-300 rpm

Contact material

Precious metal

Housing material

Aluminium alloy

Working temperature

-20℃~+60℃

IP protection grade

IP51

Through hole size

25.4 mm




Outline drawing
