Fiber optic rotary joint could improve mechanical performance, simplify operation and avoid the data loss during rotating. It can also transmit signal via fiber optic no disclose no EMI. with high protection level up To IP65, small size light weight convenient to integrate power slip ring. Relying on CENO's strong R&D ability and experienced engineering team, more and more fiber optic rotary joint model are coming out.
FCN0819-67 | Specification |
Fiber type | SM/MM |
Fiber channel | 8-19 |
Connector typ | FC/SC/LC/ST |
| Wave length range | 1270-1610nm for SM;850 and 1310nm for MM |
Insertion loss | < 5dB |
Rotation speed,max | 200rpm |
Operation temperature | -20℃～+65℃ |
Estimated life cycle | 100 million revolutions |
IP grade | IP65 |
Housing materia | Stainless stee |
| Package style | Pigtails on both ends |
Outline drawing
