RCN0118A radio frequency slip ring has 1 channel with SMA female connector. It is used for transmitting high frequency signal from rotor stator side to stator rotor side. Inside base contact material is copper and finished material is gold. It has compact structure, strong anti interference ability, easy to be integrated in other equipment. life up to 10million rotations at least with 1500W peak power.According to exact application, protection grade can be designed.
DC to 18 GHz
SMA female (50ohms)
0.25dB@0 to 6GHz
0.35dB@6 to 12GHz
0.50dB@12 to 18GHz
|IP protection grade|
