ECN000-03P2-IP65 is CENO Waterproof slip ring features 3 independent circuits with 10A current per channel, rated IP65 dustproof & waterproof for wet/outdoor rotating equipment. Adopting precious metal contact structure, it enables 360° unlimited rotation power transmission without wire tangling. Black anodized metal housing with flange mounting holes for easy installation, certified CE & RoHS compliant, factory inspected with stable low contact resistance and long service life.
Specification
| ECN000-03P2-IP65 | Specification |
|---|---|
| Protection(IP Grade) | IP65 |
| Working Humidity | 60%RH |
| WorkingTemperature | -20℃~+60℃ |
| Rating Voltage | 0~24VAC/VDC |
| Circuits& Current | 3 Circuits *10A(24V) |
| Dielectric Strength | ≥1000VAC@50Hz |
| Insulation Resistance | 500MΩ@500VDC |
| Electrical Noise | Max 30mΩ(50rpm) |
| Lead Wire Length | Rotor: 2000mm; Stator:2000mm |
| Working Speed | 0~10 rpm |
| Rotation Way | Stator side flange installation |
| Contact Material | Precious Metal |
| Housing Material | Aluminum Alloy |
