ACN25-56-FS Capsule Slip Ring

ACN25-56-FS is CENO capsule slip ring with 56 circuits signal and optional for different application. Capsule power slip ring is a collective term for a series of conductive slip rings with circular flanges ( some type without flanges ) attached to the shell. It is characterized by a compact design, small volume, easy installation, and is suitable for harsh spaces to a large extent. For more information about how CENO capsule slip ring can fit your application please contact us

Product Details

Specification

ACN25-56-FS	Specification
Current & Circuits	56 circuits * 2A
Rating Voltage	0 ~ 240 VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance wave	≤ 10mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP65
Operating speed	0~250rpm
Contact material	Precious metal
Housing material	Aluminum alloy
Outer diameter	25mm
Lead wire size	As customized
Lead wire length	As customized
Rotation way	Flange installation
