ECN000-12P3-16S-02EM Ethernet Signal Slip Ring

ECN000-12P3-16S-02EM is CENO Ethernet signal slip ring with circuits electric power and 2 circuits Ethernet. CENO has series product line, Ethernet signal slip ring is one of them, we developed products for critical applications in military, space, medical and industrial environments. Any more, a wide range of product solutions are offered with combinations of data and power in multiple mechanical configurations to meet your application requirement. For more information please contact us.

Product Details

Specification

ECN000-12P3-16S-02EM	Specification
Current & Circuits	1215A; 8Signal; 2RS422; 2Ethernet
Rating Voltage	0 ~ 280 VAC/VDC
Dielectric strength	≥1000VAC@50Hz; ≥500VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@100VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Outer diameter	Ø58mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size & length	As customized
