ECN000-01S-01F-B Integrate signal + fiber optic rotary joint

ECN000-01S-01F-B is CENO integrate signal + fiber optic rotary joint slip ring with high speed 6000rpm. CENO integrated forjs slip ring combine different electric power, signals, data with forjs together based on customer special request and application. Fiber optic rotary joint including two type mode, single and multi-mode, channels can be customized and up to dozens of channels. CENO integrate forjs slip ring works stably and often equipped on the various optoelectronic pod system.

Product Details

Specification

ECN000-01S-01F-B	Specification
Current & Circuits	1 circuit * Coaxial signal
Rating Voltage	0 ~ 240 VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥100MΩ@100VDC
Contact resistance	≦70mΩ(50rpm)
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Outer diameter	Ø20mm
Operating speed	0~6000rpm
Contact material	Precious Metal
Housing material	Aluminum alloy
Lead wire length	As customized
Fiber optic
Channel	1 * fiber optic
Fiber type	Single mode HI1060 fiber optic
Wave length	1310nm
Insert loss	≤2.0dB
Insert loss wave	≤0.7dB
Feed back loss	≤23dB
Working speed rpm	0~2000
Pigtail length & encapsulation	0.9mm white jacket; wire length 200mm
Connector type	FC/APC Connector
