ECN000-02P3-04P2-05P-33S-01F

Fiber Optic slip ring also called Fiber-Electric slip ring, Fiber Optic Rotary Joint. Adopt fiber to transmit signal, used to any devices to transmit electric and Fiber signal when 360° rotating, such as HD video transmission system, microwave communication, medical equipment, sensor signal  measurement, radar and video monitoring system  etc.

Product Details


Specification

ECN000-02P3-04P2-05P-33-01F

 Specification

Current

4*10A,2*15A,2*2A,3*7A,

33*signal,1*Video signal

Rating voltage

380VAC

Electrical noise

≤70mΩ(50rpm)

Dielectric strength

≥500VAC@50Hz(Power)

≥300VAC@50Hz(Signal)

Lead wire size

AWG14#/17#Tin coated Teflon®8U

AWG26#Tin coated Teflon®U

1.0mm2 3core& Thriced pair shield wire

0.12mm2 3 cores & twisted pair wire

Coaxial - cable RG179

Lead wire length

Rotor : 500m

Stator : 1000m

Insulation resistance

500MΩ@300VDC(Power)

100MΩ@300VDC(Signal)

Working temperature

 -40℃~+80℃

Protection grade

IP54

Insulation resistance

500MΩ@300VDC(Power)

100MΩ@300VDC(Signal)

Working temperature

 -40℃~+80℃

Protection grade

IP54

Working speed

0~300rpm

Contact material

Gold to Gold

Installation way

Rotor side fix with screws

Stator side fix with flange

Contact material

Gold to Gold

Housing material

Aluminum alloy sandblasting oxide wight



Fibe

Specification

Fiber Type

SM

Wave length

1310/1550nm

Insertion loss

<2.0dB

Insertion loss WOW

<0.5dB

Return loss

>45dB

Power of Optical

23 dBm

Wire length

Rotor: 1000+10mm

Stator: 500+10mm

Connector

LC/ LC

Housing material

Stainless steel



Outline drawing
