QCN0302-18P2-16S-01EM Integrated Pneumatic Slip Ring

QCN0302-18P2-16S-01EM is CENO new customized slip ring which combined electric power, 485 signals, servo motor, 100M Ethernet and 3 channels pneumatic rotary union. This integrated slip ring is designed for special applications where require both electric power,signals and Pneumatic transferring. This kind of slip ring can be integrated with different current, signals, pneumatic hydraulic for different applications, and it has become more and more widely concerned about various industries. For more information about how CENO slip ring can fit your specific application please contact us.

Product Details

Specification

QCN0302-18P2-16S-01EM	Specification
Current & Circuits	18circuits10A; 2group485 signal; 1group * servo motor; 1group*100M Ethernet
Rating Voltage	0~380VAC/VDC
Dielectric strength	≥1000VAC@50Hz ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC ≥100MΩ@500VDC
Contact resistance wave range	≤30mΩ (50rpm)
Contact material	Precious Metal
Housing material	Stainless steel + Aluminium Alloy
Working temperature	-20°C~+60°C
Working humidity	0~ 60%
Protection Grade	IP51
Operating speed	0~250rpm
Lead wire size	AWG17# Tin coated Teflon® UL 0.2mm² 4cores twisted shield wire 0.2mm² 8cores twisted shield wire CAT5E Net wire
Lead wire length	Rotor:5000mm; Stator:5000mm
External diameter	Ø125mm
Installation	Flange installation
Rotary Unions
Channels	3 channels * Air ( pressure air )
Interface size	G 1/4”
Pressure Max	Vacuum: ＜ -95KPa; Pressure Air: ＜ 0.8MPa
Torque	＜15N*m
