CENO Ethernet slip ring is one of the products that our company produces and sells the most, they are designed for high- speed data and error-free transmission protocols to meet the transmission requirements of various network signals, high- definition video signals, differential signals, and industrial Ethernet signals, stable data transmission, no packet loss, no serial code, low return loss, and small insertion loss with ultra-low bit error rate and ultra-high signal-to-noise ratio.
ECN025-08P1-03EG | Specification |
| Current | 8*5A, 3* group 1000M Ethernet signal |
| Voltage | 380VAC |
| Electrical noise | ≤70mΩ(50rpm) |
| Dielectric strength | ≥1000V@50Hz(power) ≥500V@50Hz(signal) |
| Insulation resistance | 500MΩ@500VDC(power) 300MΩ@100VDC(signal) |
| Operating speed | 0-300 rpm |
| Contact material | Precious metals |
| Operating temperature | -20~+60℃ |
| Through bore size | 25.4mm |
| IP protection grade | IP54 |
Outline drawing
