ECN025-04P1 High Speed Slip Ring

ECN025-04P1 is CENO high speed slip ring, which continuous rotating and transmitting power within speed around 1200rpm. CENO high speed slip ring utilize advanced technology to ensure high concentricity. Special structure treatments are employed at the contact point of stator and rotor, to ensure stable performance at high speeds. CENO have many high speed slip rings and has lifespan exceeding 100million revolutions over 1000rpm. For more information please contact us.

Product Details

Specification

ECN025-04P1	Specification
Current & Circuits	4 circuits * 5A
Rating Voltage	0 ~ 24 VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~1200rpm
Inner diameter	Ø25mm
Outer diameter	Ø60mm
Contact material	Gold to gold
Housing material	Aluminium Alloy
Lead wire size	As customized
Lead wire length	As customized
