HCN000-02P3 Flat Pin Slip Ring

HCN000-02P3 is CENO insert type slip ring with 2 pins. The insert slip ring is an economical, compact and reliable rotary connection solution. It is very suitable for equipment with space and cost requirements. Due to HCN series slip rings feature a sophisticated design, using pins instead of wires for contact. They comply with RoHS regulations and are widely used on kinds of modern machinery, such as the assembly line equipment, cable reel etc. For more information please contact us.

Product Details

Specification

HCN000-02P3	Specification
Current & Circuits	2 circuits * 15A
Rating Voltage	0 ~ 240 VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥100MΩ@500VDC
Contact resistance wave	≤ 10mΩ
Working temperature	-20°C~+80°C
Working humidity	60 %RH
Operating speed	0~400rpm
Contact material	Precious metal
Housing material	Engineering plastics
