ECN000-03P4-02F-IP65 Integrate Power and FORJs Slip Ring

ECN000-03P4-02F-IP65 is CENO integrate slip ring combine 3 circuits 20A power and 2 channels fiber optic rotary joints that suit for medical equipment, radar system and material conveying system etc. CENO integrate forjs slip rings is a customized non-standards series, designed for different special applications, supports multi-channel and multi-specification customization to meet various complex operating environments. For more information please contact us.

Product Details

Specification

ECN000-03P4-02F-IP65	Specification
Current & Circuits	3 circuits * 20A
Rating Voltage	0 ~ 1000 VAC/VDC
Dielectric strength	≥1500VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP65
Operating speed	0~100rpm
Outer diameter	Ø86mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size & length	As customized
Fiber Optic Rotary Joint
Fiber type	SM (9/125um)
Fiber Channel	2
Wavelength	1310~1550nm
Insertion Loss	< 3.5dB
Return Loss	>45dB
Peak power, max	23dBm
Protection (IP Grade)	IP65
Connector	LC/ LC
