QCN0102-03P4-06P2-03EG Integrate Pneumatic/hydraulic Slip Ring

QCN0102-03P4-06P2-03EG is CENO integrate pneumatic hydraulic slip ring which combine electric power, Ethernet signal and one channel pneumatic rotary union. CENO integrate pneumatic hydraulic slip ring designed for the special application where require both electric power slip ring and pneumatic hydraulic rotary union. The channels, pressure, connect type and tube size are optional as customer different environment. For more information please contact us.

Product Details

Specification

QCN0102-03P4-06P2-03EG	Specification
Current & Circuits	3 * 20A; 6 * 10A; 1 * PE; 3 * 1000M Ethernet signal
Rating Voltage	0 ~ 220 VAC/VDC
Dielectric strength	≥1000VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@100VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~50rpm
Outer diameter	Ø86mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size	As customized
Lead wire length	As customized
Rotary union
Channels	1 channel * Pneumatic
Tube	Ø8mm
Pressure	≤1.0MPa
