QCN01M6-04P2-04S Integrate Pneumatic Hydraulic Slip Ring

QCN01M6-04P2-04S is CENO integrate pneumatic hydraulic slip ring that combine circuits electric power, signal and 1 channel air. Integrate slip ring is characterized by its high degree of integration, which simplifies system design while enabling multifunctional transmission. Compared to the simple slip ring, the integrated slip ring is more compact, significantly saving installation space and reducing weight. For more information please contact us.

Product Details

Specification

QCN01M6-04P2-04S	Specification
Current & Circuits	4 circuits * 10A; 4 circuits * Signal
Rating Voltage	0 ~ 220 VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥100MΩ@100VDC
Contact resistance wave	≤ 30mΩ (50rpm)
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~90rpm
Outer diameter	Ø110mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Rotation way	Flange installation
Lead wire size	As customized
Lead wire length	As customized
Rotary Joints
The road	1 channel Air (M6*1.0 & Ø4mm tube)
Pressure Max	145 PSI
