ECN000-84P Encoder Integrated Slip Ring

ECN000-84P is CENO Encoder integrated slip ring with multi-channels automatic industrial applications, CENO has produce and manufacture around 5000 designs in past twenty years. Most of these products are developed for rugged environments and demanding requirements, take Encoder integrated slip ring for example, the typical applications include Electro-optic systems, Engineering Machinery, Ship crane, Offshore equipment or Oil well drilling. Most of the parameters as channels, circuits, protection grade, installation and integrated signals are optional. More information please contact us.

Product Details

Specification

ECN000-84P	Specification
Current & Circuits	8circuits25A; 8circuits15A; 16circuits10A; 29circuits5A; 8circuits2A; 2circuits1A; 2Group*Encoder signal
Rating Voltage	0~380VAC/VDC
Dielectric strength	≥1500VAC@50Hz ≥500VAC@50Hz
Isolation resistance	≥500MΩ@500VDC ≥100MΩ@300VDC
Electrical Noise	30mΩ (50rpm)
Contact material	Precious Metal / Gold to gold
Housing material	Aluminum Alloy
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP54
Operating speed	0~300rpm
Lead wire length	Rotor : 1500mm Stator : 3000mm
External diameter	Ø99mm
