ECN055-03P4-18S-01EM Low Temperature Slip Ring

ECN055-03P4-18S-01EM is CENO low temperature slip ring with through hole 55mm and combine electric power with Ethernet signal for the equipment working in low temperature from -40°C to +70°C. Low-temperature slip rings refer to electrical slip rings that can maintain stable electrical energy/signal transmission under extreme low-temperature conditions. Often used to cryogenic equipment, polar wind power, and aerospace rotating platforms etc,. More information please contact us.

Product Details

Specification

ECN055-03P4-18S-01EM	Specification
Current & Circuits	3 * 20A; 18 * 5A; 1 * 100M Ethernet
Dielectric strength	≥1500VAC@50Hz; ≥500VAC@50Hz
Isolation resistance	≥100MΩ@1500VDC; ≥200MΩ@500VDC
Contact resistance wave	≤ 10mΩ
Working temperature	-40°C~+70°C
Working humidity	60 %RH
IP protection grade	IP54
Operating speed	0~50rpm
Inner diameter	Ø55mm
Outer diameter	Ø99mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size & length	As customized
Installation	As customized
