ECN090-03P3-09P1 Low Temperature Slip Ring

ECN090-03P3-09P1 is CENO low temperature slip ring with through hole 90mm and 12 circuits Electric Power. Low-temperature slip rings refer to electrical slip rings that can maintain stable electrical energy　/ signal transmission under extreme low-temperature conditions. The core design and technical challenges lie in breakthroughs in material selection and optimization of structure and manufacturing processes. For information about how CENO slip ring can be tailored to your operating please contact us.

Product Details

Specification

ECN090-03P3-09P1	Specification
Current & Circuits	3 circuits * 15A; 9 circuits * 5A
Rating Voltage	0 ~ 380 VAC/VDC
Dielectric strength	≥1000VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance wave	≤ 70mΩ
Working temperature	-40°C~+80°C
Working humidity	90 %RH
IP protection grade	IP54
Operating speed	0~50rpm
Inner diameter	Ø90mm
Outer diameter	Ø160mm
Contact material	Precious metal
Housing material	Aluminium Alloy
Lead wire size & length	As customized
Rotation Way	Stator side fixed to main shaft
