ECN000-05P1-04S-01EG-01F Integrate Ethernet signal and FORJs Slip Ring

ECN000-05P1-04S-01EG-01F is CENO Integrate electric power signal and fiber optic rotary joint slip ring, that is equipped in the machine working in low temperature -40°C~+50°C. Slip ring is an electro-mechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. CENO integrate fiber optic rotary joint slip rings are developed for rugged environment and demanding requirements, and performing in aerospace and defense application.

Product Details

Specification

ECN000-05P1-04S-01EG-01F	Specification
Current & Circuits	5 circuits * 5A; 4circuits * signal; 1 * Fiber optic
Rating Voltage	0 ~ 220 VAC/VDC
Dielectric strength	≥1000VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@300VDC
Contact resistance wave	≤ 10mΩ
Working temperature	-40°C~+50°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Outer diameter	Ø56mm
Contact material	Precious Metal
Housing material	Aluminum Alloy
Lead wire length	As customized
Installation way	Flange installation
Fiber Optic
Wave length	1310/1550
Insert loss	＜2dB
Return loss	＜30dB
Insertion loss deviation	＜±0.5dB
Connector	FC
Cable length	As customized
