ECN000-08P2-04S-02R Integrate Power & RF Slip Ring

ECN000-08P2-04S-02R is CENO integrate slip ring combined circuits electric power and 2 channels RF signal that can be used in medical equipment - CT Scan machine. CENO works with many CT system manufacture to provide reliable large diameter slip ring solutions. Our experienced engineers work with you every step of the way to ensure that your integrate RF slip ring is tailored to your specifications and performance needs. Mobile base stations Satellite communications Weather radar Autonomous driving sensors Internet of Things.

Product Details

Specification

ECN000-08P2-04S-02R	Specification
Current & Circuits	8 circuits * 10A; 4 circuits * Signal
Rating Voltage	0 ~ 440 VAC/VDC
Dielectric strength	≥1000VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@300VDC; ≥100MΩ@300VDC
Contact resistance wave	≤ 10mΩ
Working temperature	-40°C~+80°C
Working humidity	90 %RH
IP protection grade	IP54
Operating speed	0~250rpm
Outer diameter	Ø80mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size	As customized
Lead wire length	As customized
High Radio frequency	Channel 1	Channel 2
Connector type	SMA-f (50Ω)	SMA-f (50Ω)
Frequency range	DC to 4.5GHz	DC to 4.5GHz
Wave ratio max	1.2	1.6
Wave ratio floating max	0.1	0.2
Insertion loss max	0.3dB	0.5dB
Insertion loss wow max	0.1dB	0.2dB
Peak power	1000w	1000w
Average power	50w @ 1GHz	50w @ 1GHz
