SCN035-04P1 Separate Slip Ring

SCN035-04P1 is CENO separate slip ring, that is suitable for high-end industrial and technological fields that require high convenience, maintainability, and modular design, and solves the installation and maintenance difficulty of traditional slip rings. No need to thread the equipment shaft during installation, avoiding the trouble of disassembling the entire equipment. This realizes the “ install first, then dock split installation process. For more information please contact us.

Product Details

Specification

SCN035-04P1	specification
Current & Circuits	4 circuits * 3A
Rating Voltage	0 ~ 380 VAC/VDC
Dielectric strength	≥1000VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+80°C
Working humidity	60 %RH
IP protection grade	IP00
Operating speed	0~300rpm
Inner diameter	Ø35mm
Outer diameter	Ø61mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size	As customized
Lead wire length	As customized
