ECN050-09P3-01EG Ethernet Signal Slip Ring

ECN050-09P3-01EG is Ethernet Signal Slip Ring with Gigabit Ethernet signal and Electric power for industry. CENO as a leading manufacturer of slip rings, our Ethernet slip ring solutions have been developed to provide reliable products to allow transfer of the Ethernet protocol through a rotating interface. our slip rings are uniquely suited for critical Ethernet applications. For more information about how CENO slip ring can fit your equipment, please contact us.

Product Details

Specification

ECN050-09P3-01EG	Specification
Current & Circuits	9 circuits * 15A; 1 Group * 1000M Ethernet
Rating Voltage	0 ~ 220 VAC/VDC
Dielectric strength	≥1000VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@300VDC
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Inner diameter	Ø50mm
Outer diameter	Ø119mm
Contact material	Gold to gold
Housing material	Aluminum alloy
Lead wire size	As customized
Lead wire length	As customized
