ECN038-16P4 Power Slip Ring

ECN038-16P4 is CENO power slip ring with through hole 38mm. Power slip rings, also commonly called conductive slip rings, collector rings, or rotary joints. Principle is that the brushes maintain constant contact with the corresponding conductive ring surface. When the rotor rotates with the equipment, the conductive rings rotate synchronously while the brushes remain stationary. Often used in industrial robots, rotary tables, and medical CT equipment. For more information please contact us.

Product Details

Specification

ECN038-16P4	Specification
Current & Circuits	16 circuits * 16A
Rating Voltage	0 ~ 380 VAC/VDC
Dielectric strength	≥1000VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Inner diameter	Ø38mm
Outer diameter	Ø99mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Lead wire size & length	As customized
Installation	Rotor side fixed to main shaft with screws
