ECN095-08S Industry Slip Ring

ECN095-08S is CENO industry slip ring have through hole in center and combine circuits signal and one channel CANBUS signal, that is designed for industrial system. Through hole is a kind of classical design for easy and firmly installed on the rotation main shaft by screws, the other side installed by anti-rotation tab on machine stator side. Slip ring continuous rotating and transmitting signal and power from one side to other side. For more information please contact us.

Product Details

Specification

ECN095-08S	Specification
Current & Circuits	1 * CanBus; 1 * Signal; 4 * Signal
Rating Voltage	0 ~ 24 VAC/VDC
Dielectric strength	≥300VAC@50Hz
Isolation resistance	≥100MΩ@300VDC
Contact resistance wave	≤ 30mΩ
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~50rpm
Inner diameter	Ø95mm
Outer diameter	Ø185mm
Contact material	Precious Metal
Housing material	Aluminium Alloy
Rotation way	Fix up stator side with anti-rotation tab
Lead wire length	As customized
