HDMI High Definition Slip Rings

CENO'S HDMI slip ring adopts domestic leading military technology, it has the advantages on transmission stability, attenuation loss of signal and ultra-low transmission fluctuation.This kind of high definition slip ring includes SDI high resolution and HDMI, which transmits electrical signals ,video signals and high-speed digital signals to meet EMC requirements.CENO also can provide different solutions according to customer's requirements.

Product Details

Feature

It can support video standard of 2K@90Hz,no flicker screen and losing frame

Gold to gold contact point to guarantee extending working lifespan

Low contact resistance, compact size, low torque, reliable operation




Application

HDMI Security system

Infrared photography

High definition PTZ

Photooelectric pod

Radar antenna





ModelI

ID

(mm)

OD

(mm)

CKT

No.

Current/Signal VoltageWorking speedSpec
ACN-24S-04RF
0242824*signal ;4*RF signal0~110V AC/DC0~10rpm1-22050GA94X19.jpg
ACN25J-04P1-30P-01HD-01EM 0
2536

30*2A,4*5A,1*HD-SDI,1*Gigabit Ethernet.

0-110 VAC/DC0-200 rpm1-22050GA94X19.jpg
ACN-30S-01EG-01UB-01HD-01R
04533
30* 2A, 1*Gigabit signal 1*USB,1*HD-SDI100VAC/VDC
ECN000-02P1-02P2-02P-30S-HD
062
362*10A,2*5A,2*2A,29*1A,1*video, 1*(HD-SDI)380VAC0~30rpm1-22050GA94X19.jpg
ECN000-03P-04P2-23S-01HD
04931
3*20A ,4*10A ,23*signal ,1*coaxial signal440VAC/250VDC0-100 rpm1-22050GA94X19.jpg
ECN000-04P1-02U2-01HD
07674*5A, 2*USB2.0 ,1*HDMI signal380VAC0~30rpm1-22050GA94X19.jpg
ECN000-07P-25S-01EG-01HD086
33

4*5A,3*10A,2*2A,4*RS422,1*1000M Ethernet,1*HDSDI,9*signal

220VAC/24VDC

0-150 rpm1-22050GA94X19.jpg
ECN004-04P-01S
4
3551*coaxial signal,4* ordinary signal380VAC0~400rpm1-22050GA94X19.jpg
ECN012-05P2-02S-HD02
12569
2*video signal, 2*DP signal, 5*10A220VAC/12VAC0~300rpm1-22050GA94X19.jpg
ECN038-32S-03HD
38993532*1A, 3*Bandwidth0~150 VAC/VDC

0-250 rpm
